When it comes to electrical safety, particularly arc flash protection, personal protective equipment (PPE) plays a critical role. NFPA 70E outlines specific PPE categories designed to protect against arc flash hazards.
An arc flash is a sudden release of energy caused by an electrical fault. When that happens, the energy generates intense heat, a pressure wave, and flying debris, which can cause injuries and even death. NFPA 70E (guidelines created by the National Fire Protection Association) has established arc flash categories that specify the level of PPE required based on the potential incident energy exposure.
The Four PPE Arc Flash Categories
Category 1: Minimum Arc-Rated PPE
- Arc Rating: 4 cal/cm²
- Required PPE:
- Arc-rated long-sleeve shirt and pants or arc-rated coverall
- Arc-rated face shield or arc flash suit hood
- Hard hat
- Safety glasses
- Leather gloves
- Hearing protection
Category 1 is the lowest level of arc flash protection. The arc rating indicates the level of heat energy the PPE can withstand before allowing a second-degree burn to happen.
Category 2: Enhanced Arc-Rated PPE
- Arc Rating: 8 cal/cm²
- Required PPE:
- Arc-rated long-sleeve shirt and pants or arc-rated coverall
- Arc-rated face shield or arc flash suit hood
- Hard hat
- Safety glasses
- Leather gloves
- Hearing protection
Category 2 provides a higher level of protection compared to Category 1. The arc rating means that the PPE can withstand more heat energy, making it suitable for tasks with moderate arc flash risk.
Category 3: Advanced Arc-Rated PPE
- Arc Rating: 25 cal/cm²
- Required PPE:
- Arc-rated long-sleeve shirt and pants or arc-rated coverall
- Arc-rated face shield and balaclava or arc flash suit hood
- Hard hat
- Safety glasses
- Leather gloves
- Hearing protection
- Arc-rated jacket, parka, rainwear, or hard hat liner (if applicable)
Category 3 represents a significant increase in protection, necessary for tasks with higher arc flash risks.
Category 4: Maximum Arc-Rated PPE
- Arc Rating: 40 cal/cm²
- Required PPE:
- Arc-rated long-sleeve shirt and pants or arc-rated coverall
- Arc-rated face shield and balaclava or arc flash suit hood
- Hard hat
- Safety glasses
- Leather gloves
- Hearing protection
- Arc-rated jacket, parka, rainwear, or hard hat liner (if applicable)
Category 4 provides the highest level of protection for the tasks with the highest risk of arc flash incidents.
How to Choose the Right PPE Category
Choosing the appropriate PPE category is crucial for worker safety. The way to know which category is right for which worker/which task is to conduct a thorough arc flash risk assessment to identify the potential incident energy exposure and select the correct PPE category. If you don’t know the energy exposure, you could end up spending more than you need to on PPE, or much worse, not protecting your employees.
